19.2V 6Ah 6S2P Grass Cutter Battery

Product Introduction:
PLB lawn mower battery, is specially designed for the need of external parallel battery design, using plastic shell, internal structure is stable. With intelligent control, high stability, high safety and other characteristics, can realize multiple battery banks in parallel.
Application Scenarios:
Lawn mower
Features:
• Maximum support 1C fast charging, 1C continuous discharge, strong power.
• High capacity design, high capacity density, long battery life
• Low-power solution, longer standby time.
• With handle design for easy handling
• Complete lithium battery protection function, over charge/over discharge/over current/short circuit protection/temperature protection, to ensure the safe use of lithium batteries
• Long life, high stability,
• CAN communication, supporting external parallel connection

Inquiry

Electrical Specifications
Nominal Voltage	19.2V
Nominal Capacity	6Ah
Energy	115.2Wh
Internal Resistance	≤50mΩ
Self Discharge	<1% Per Month
Series and Parallel	/

Mechanical Specifications
Dimensions (L x W x H)	27017231mm
Weight	1.5Kg
Terminal	/
Case Material	PVC
IP Rating	IP42
Cells	26650 – LiFePO4

Discharge Specification
Max Continuous Discharge Current	15A
Max Instantaneous Discharge Current	/
BMS Discharge Protection Current	21A
Overdischarge Protection Voltage	12V
Overdischarge Recovery Voltage	15V
Short Circuit Protection	800uS

Charge Specifications
Charge Current	3A
Max Charge Current	6A
Charge Voltage	21.9V
Overcharge Protection Voltage	22.2V
Overcharge Recovery Voltage	21.6V
Equalization Turn-on Voltage	/

Temperature Specification
Discharge Temperature	-20-60℃
Charge Temperature	0-45℃
Storage Temperature	-5-45℃
BMS Over Temperature Protection	65±5℃
BMS Over Temperature Protection Recovery	55±5℃

Communication
Communication	/


Compliance Specification
Certification	UN38.3

Charging SOC Curve

Discharge SOC Curve

Maximum Charge Current Curve

Maximum Discharge Current Curve

Different Dod Cycle Life Diagram (1c Charge, 0.5c Discharge @ 25℃)

2D Drawing
