3.2V 3.3Ah 1S1P Emergency Light Battery
  • 3.2V 3.3Ah 1S1P Emergency Light Battery
  • 3.2V 3.3Ah 1S1P Emergency Light Battery
  • 3.2V 3.3Ah 1S1P Emergency Light Battery
Electrical Specifications
Nominal Voltage3.2V
Nominal Voltage3.3Ah
Energy10.56Wh
Internal Resistance≤105mΩ
Self Discharge<1% Per Month
Series and Parallel/
Mechanical Specifications
Dimensions (L x W x H)φ26.5*70mm
Weight0.1Kg
TerminalKR2001H-02P
Case MaterialPVC
IP RatingIP42
Cells26650 – LiFePO4
Discharge Specification
Max Continuous Discharge Current3A
Max Instantaneous Discharge Current/
BMS Discharge Protection Current7A
Overdischarge Protection Voltage2V
Overdischarge Recovery Voltage2.5V
Short Circuit Protection800uS
Charge Specifications
Charge Current1.6A
Max Charge Current3A
Charge Voltage3.65V
Overcharge Protection Voltage3.9V
Overcharge Recovery Voltage3.75V
Equalization Turn-on Voltage/
Temperature Specification
Discharge Temperature-20-60℃
Charge Temperature0-45℃
Storage Temperature-5-45℃
BMS Over Temperature Protection65±5℃
BMS Over Temperature Protection Recovery55±5℃
Communication
Communication/


Compliance Specification
CertificationUN38.3

0.2c, 0.5c, 1c Discharge Curve

3.2V 3.3Ah 1S1P Emergency Light Battery

Discharge Curves at Different Temperatures: 60°c, 25°c, 0°c, -10°c

3.2V 3.3Ah 1S1P Emergency Light Battery

Charging Curves at Different Temperatures: 45°c, 25°c, 0°c

3.2V 3.3Ah 1S1P Emergency Light Battery

2D Drawing

3.2V 3.3Ah 1S1P Emergency Light Battery
