Electrical Specifications | |
Nominal Voltage | 25.2V |
Nominal Capacity | 60.5V |
Energy | 1524.6V |
Internal Resistance | ≤60mΩ |
Self Discharge | <1% Per Month |
Series and Parallel | / |
Mechanical Specifications | |
Dimensions (L x W x H) | 321*201*71mm |
Weight | 8.3 Kg |
Terminal | / |
Case Material | SPCC |
IP Rating | IP42 |
Cells | 26650 – Li(NiCoMn)O2 |
Discharge Specification | |
Max Continuous Discharge Current | 15A |
Max Instantaneous Discharge Current | / |
BMS Discharge Protection Current | 60A |
Overdischarge Protection Voltage | 19.6V |
Overdischarge Recovery Voltage | 20.3V |
Short Circuit Protection | ≤800uS |
Charge Specifications | |
Charge Current | 8A |
Max Charge Current | 15A |
Charge Voltage | 29.925V |
Overcharge Protection Voltage | 29.925V |
Overcharge Recovery Voltage | 28.525V |
Equalization Turn-on Voltage | / |
Temperature Specification | |
Discharge Temperature | -20-60℃ |
Charge Temperature | 0-45℃ |
Storage Temperature | -5-45℃ |
BMS Over Temperature Protection | 65±5℃ |
BMS Over Temperature Protection Recovery | 55±5℃ |
Communication | |
Communication | RS485 |
Compliance Specification | |
Certification | / |
Charging SOC curve

Discharge SOC curve

30A charging current curve

40A discharge current curve

Different DOD cycle life diagram(+1C/[email protected]℃)
2D Drawing
