46.2V 43.2Ah 14S12P AGV Battery
  • 46.2V 43.2Ah 14S12P AGV Battery
  • 46.2V 43.2Ah 14S12P AGV Battery
  • 46.2V 43.2Ah 14S12P AGV Battery
Electrical Specifications
Nominal Voltage44.8V
Nominal Voltage43.2Ah
Energy1935.36Wh
Internal Resistance≤50mΩ
Self Discharge<1% Per Month
Series and Parallel/
Mechanical Specifications
Dimensions (L x W x H)581*187*143MM
Weight21KG
TerminalWeipu: WF20K4Z , 4PIN
Case MaterialSPCC
IP RatingIP42
Cells26650 – LiFePO4
Discharge Specification
Max Continuous Discharge Current40A
Max Instantaneous Discharge Current/
BMS Discharge Protection Current50A
Overdischarge Protection Voltage40V
Overdischarge Recovery Voltage48V
Short Circuit Protection600uS
Charge Specifications
Charge Current15A
Max Charge Current40A
Charge Voltage51.1V
Overcharge Protection Voltage60V
Overcharge Recovery Voltage57.6V
Equalization Turn-on Voltage56V
Temperature Specification
Discharge Temperature-20-60℃
Charge Temperature0-45℃
Storage Temperature-5-45℃
BMS Over Temperature Protection65±5℃
BMS Over Temperature Protection Recovery55±5℃
Communication
CommunicationRS485


Compliance Specification
Certification/

Charging SOC curve

46.2V 43.2Ah 14S12P AGV Battery

Discharge SOC curve

46.2V 43.2Ah 14S12P AGV Battery

30A charging current curve

46.2V 43.2Ah 14S12P AGV Battery

40A discharge current curve

46.2V 43.2Ah 14S12P AGV Battery

Different DOD cycle life diagram(+1C/-0.5C@25℃)

46.2V 43.2Ah 14S12P AGV Battery

2D Drawing

2D Drawing
