25.6V 19.8AH 8S6P Medical Battery
  • 25.6V 19.8AH 8S6P Medical Battery
  • 25.6V 19.8AH 8S6P Medical Battery
  • 25.6V 19.8AH 8S6P Medical Battery
Electrical Specifications
Nominal Voltage25.6V
Nominal Voltage19.8Ah
Energy506.88wh
Internal Resistance≤60mΩ
Self Discharge<1% Per Month
Series and Parallel/
Mechanical Specifications
Dimensions (L x W x H)226*137*103mm
Weight5KG
TerminalT-Plug
Case MaterialPVC
IP RatingIP42
Cells26650 – LiFePO4
Discharge Specification
Max Continuous Discharge Current15A
Max Instantaneous Discharge Current/
BMS Discharge Protection Current30A
Overdischarge Protection Voltage21.6V
Overdischarge Recovery Voltage24V
Short Circuit Protection≤600uS
Charge Specifications
Charge Current3.84A
Max Charge Current15A
Charge Voltage29.2V
Overcharge Protection Voltage30V
Overcharge Recovery Voltage28.8V
Equalization Turn-on Voltage27.2V
Temperature Specification
Discharge Temperature -20-60℃
Charge Temperature 0-45℃
Storage Temperature -5-45℃
BMS Over Temperature Protection 65±5℃
BMS Over Temperature Protection Recovery 55±5℃
Communication
CommunicationRS485


Compliance Specification
CertificationUN38.3

Charging SOC Curve

25.6V 19.8AH 8S6P Medical Battery

Discharge SOC Graph

25.6V 19.8AH 8S6P Medical Battery

Maximum Charge Current Curve

25.6V 19.8AH 8S6P Medical Battery

Maximum Discharge Current Curve

25.6V 19.8AH 8S6P Medical Battery

Different DOD cycle life diagram (1C charge 0.5C discharge @25℃)

25.6V 19.8AH 8S6P Medical Battery

2D Drawing

25.6V 19.8AH 8S6P Medical Battery
