48V 60Ah 13S12P AGV Battery
  • 48V 60Ah 13S12P AGV Battery
  • 48V 60Ah 13S12P AGV Battery
  • 48V 60Ah 13S12P AGV Battery
Electrical Specifications
Nominal Voltage48V
Nominal Voltage60AH
Energy2880WH
Internal Resistance≤50mΩ
Self Discharge<1% Per Month
Series and Parallel/
Mechanical Specifications
Dimensions (L x W x H)580*145*190MM
Weight22.9KG
TerminalWeipu WF20K4Z -1-4P
Case MaterialSPCC
IP RatingIP42
CellsWeipu WF20K4Z -1-4P
Discharge Specification
Max Continuous Discharge Current50A
Max Instantaneous Discharge Current/
BMS Discharge Protection Current60A
Overdischarge Protection Voltage36.4V
Overdischarge Recovery Voltage39V
Short Circuit Protection≤600uS
Charge Specifications
Charge Current12A
Max Charge Current50A
Charge Voltage54.6V
Overcharge Protection Voltage55.25V
Overcharge Recovery Voltage53.95V
Equalization Turn-on Voltage52V
Temperature Specification
Discharge Temperature-20-60℃
Charge Temperature0-45℃
Storage Temperature-5-45℃
BMS Over Temperature Protection65±5℃
BMS Over Temperature Protection Recovery55±5℃
Communication
CommunicationRS485


Compliance Specification
Certification/

Charging SOC curve

48V 60Ah 13S12P AGV Battery

Discharge SOC curve

48V 60Ah 13S12P AGV Battery

30A charging current curve

48V 60Ah 13S12P AGV Battery

40A discharge current curve

48V 60Ah 13S12P AGV Battery

Different DOD cycle life diagram(+1C/-0.5C@25℃)

48V 60Ah 13S12P AGV Battery

2D Drawing

2D Drawing
