| Model NO. | 25.6V6Ah | 38.4V6Ah | 51.2V6Ah | 76.8V6Ah | 96V6Ah | 192V6Ah |
| Voltage | 25.6V | 38.4V | 51.2V | 76.8V | 96V | 192V |
| Capacity | 6Ah | 6Ah | 6Ah | 6Ah | 6Ah | 6Ah |
| Operating voltage | 20V~28.8V | 30V~43.2V | 40V~57.6V | 60V~86.4V | 75V~108V | 150V~216V |
| Standard Charge Current | 6A | 6A | 6A | 6A | 6A | 6A |
| Max Continuous Discharge Current | 45A | 45A | 45A | 45A | 45A | 45A |
| Battery type | LiFePO4（10C discharge） | |||||
| Design life | 11 years | |||||
| IP rating | IP21 | |||||
| Charge temperature | 0～45℃ | |||||
| Discharge temperature | -20～60℃ | |||||
| Module parallel | 3 | |||||
| Dimension | customized | customized | customized | customized | customized | customized |
| Weight | 2.08Kg | 3.12Kg | 4.16Kg | 6.24Kg | 8.32Kg | 15Kg |
| Communication | RS485（optional） | |||||
| Standard Compliance | UL1973、IEC62619、UN38.3 | |||||
