Model NO. | 25.6V12Ah | 38.4V12Ah | 51.2V9Ah | 76.8V9Ah | 192V6Ah |
Voltage | 25.6V | 38.4V | 51.2V | 76.8V | 192V |
Capacity | 12Ah | 12Ah | 9Ah | 9Ah | 6Ah |
Operating voltage | 20V~28.8V | 30V~43.2V | 40V~57.6V | 60V~86.4V | 150V~216V |
Standard Charge Current | 12A | 12A | 9A | 9A | 6A |
Max Continuous Discharge Current | 45A | 45A | 45A | 45A | 45A |
Battery type | LiFePO4（10C discharge） | ||||
Design life | 11 years | ||||
IP rating | IP21 | ||||
Charge temperature | 0～45℃ | ||||
Discharge temperature | -20～60℃ | ||||
Module parallel | 3 | ||||
Dimension | 438*450*43 | 438*450*43 | 438*450*43 | 438*540*43 | 438*730*43 |
Weight | 7.3Kg | 8.5Kg | 8.5Kg | 11.2Kg | 16Kg |
Communication | RS485 | ||||
Standard Compliance | UL1973、IEC62619、UN38.3 | ||||
