48V 26AH LiFePO4 AGV Battery Pack
  • 48V 26AH LiFePO4 AGV Battery Pack
  • 48V 26AH LiFePO4 AGV Battery Pack
  • 48V 26AH LiFePO4 AGV Battery Pack
Electrical Specifications
Nominal Voltage48V
Nominal Capacity26Ah
Energy1248Wh
Internal Resistance40mΩ
Self Discharge<1% Per Month
Series and Parallel15S8P
Cycle life2000
Mechanical Specifications
CellsIFR26650-3300mAh
Dimensions (L x W x H)530*155*128mm
Weight17Kg
TerminalSAS50A(gray, red)
Case MaterialSPCC
IP RatingIP42
Discharge Specifications
Discharge Current13.2A
Max Continuous Discharge Current60A
BMS Overdischarge Protection Current70A
Overdischarge Protection Voltage37.5V
Overdischarge Recovery Voltage45V
Short Circuit Protectionyes



Charge Specifications
Charge Current13.2A
Max Charge Current52.8A
Charge Voltage54.75V
Overcharge Protection Voltage56.25V
Overcharge Recovery Voltage54V
Equalization Turn-on Voltage52.5V
Temperature Specification
Discharge Temperature-20-60℃
Charge Temperature0-45℃
Storage Temperature-5-45℃
BMS Over Temperature Protectio65±5℃
BMS Over Temperature Protection Recovery55±5℃
Communication
CommunicationRS485


Compliance Specification
Certification/

Charging SOC curve

48V 26AH LiFePO4 AGV Battery Pack

Discharge SOC curve

48V 26AH LiFePO4 AGV Battery Pack

Curve of maximum charging current

48V 26AH LiFePO4 AGV Battery Pack

Curve of maximum discharge current

48V 26AH LiFePO4 AGV Battery Pack

2D Diagram

48V 26AH LiFePO4 AGV Battery Pack

Cycle life diagram of different DODs (1C charge, 0.5C discharge @ 25 ℃)

48V 26AH LiFePO4 AGV Battery Pack
