24V 45Ah lithium battery
24V 45Ah LiFePO₄ Lithium Battery – Lightweight, Efficient, and Built for Performance
The 24V 45Ah LiFePO₄ lithium battery provides 1.15kWh of stable, high-efficiency power in a compact and portable form. Designed for space-constrained applications like portable solar systems, RV and marine electronics, telecom backup, and light industrial equipment, this battery offers outstanding safety, long cycle life, and maintenance-free operation.
With Lithium Iron Phosphate (LiFePO₄) technology, it delivers higher efficiency, longer service life, and more usable capacity than lead-acid batteries—making it the smart choice for modern energy systems.
What Is a 24V 45Ah LiFePO₄ Battery?
This battery utilizes advanced LiFePO₄ chemistry paired with an integrated Battery Management System (BMS) for intelligent protection and optimal performance. It’s designed to deliver consistent power, support deep discharge, and enable fast charging while remaining safe and thermally stable across a wide temperature range.
Key Features
Total Energy: 1.15kWh
Long Life Cycle: 6,000+ cycles at 80% depth of discharge (DoD)
Smart BMS: Built-in protection against overcharge, over-discharge, short circuits, overheating, and overcurrent
High Efficiency: >98% round-trip energy efficiency
Compact and Lightweight: Perfect for mobile or space-limited installations
Fast Charging & High Discharge Rates
Zero Maintenance: No water refills, no acid leaks, no corrosion
Eco-Friendly: RoHS and CE certified; non-toxic and recyclable
Customizable Options: Connectors, casing, communication (CAN, RS485) available upon request
Technical Specifications (Typical)
| Parameter | Specification |
|---|---|
| Nominal Voltage | 25.6V |
| Rated Capacity | 45Ah |
| Total Energy | 1.15kWh |
| Charge Voltage | 29.2V |
| Cut-off Voltage | 20.0V |
| Max Charge Current | Up to 20A (adjustable) |
| Max Discharge Current | Up to 45A (adjustable) |
| Operating Temperature | -20°C to +60°C |
| Cycle Life | 6,000+ cycles @ 80% DoD |
| Protection Class | IP65 or higher (optional) |
| Approx. Weight | ~8–10kg |
Common Applications
Portable and Off-Grid Solar Systems
Recreational Vehicles (RVs) and Campers
Small Boats and Marine Electronics
Telecom and IoT Backup Power
Medical Devices and Instrumentation
Mobile Workstations and Equipment
Emergency Lighting Systems
LiFePO₄ vs. Lead-Acid: A Superior Choice
| Feature | LiFePO₄ 24V 45Ah | Lead-Acid Equivalent |
|---|---|---|
| Usable Capacity | ~100% | ~50% |
| Cycle Life | 6,000+ cycles | 500–1,000 cycles |
| Maintenance | None | Requires regular upkeep |
| Weight | Lightweight | Heavier |
| Charging Time | Fast | Slow |
| Safety | High thermal stability | Risk of acid leaks/spills |
The 24V 45Ah LiFePO₄ lithium battery offers a smart, compact, and high-performance power solution for users who demand safety, reliability, and longevity. Whether used in mobile systems, backup units, or compact solar setups, this battery delivers clean, stable power you can count on—without the hassle of maintenance.
Upgrade your energy storage with LiFePO₄—compact, powerful, and built to last.
