Electrical Specifications | |
Nominal Voltage | 48V |
Nominal Capacity | 6Ah |
Energy | 288Wh |
Internal Resistance | ≤75mΩ |
Self Discharge | <1% Per Month |
Series and Parallel | 4P |
Matched UPS | ≤2KVA |
Mechanical Specifications | |
Cells | IFR26650-3000mAh |
Cell in Series and Parallel | 15S2P |
Dimensions (L x W x H) | 181*77*167mm |
Weight | 3.4Kg |
Terminal | M5 |
Case Material | ABS+PC |
IP Rating | IP65 |
Discharge Specification | |
Backup time | 8~15min |
Max Continuous Discharge Current | 42A |
Overdischarge Protection Voltage | 33V |
Overdischarge Recovery Voltage | 40.5V |
Short Circuit Protection | yes |
Charge Specifications | |
Charge Current | 6A |
Charge Voltage | 54V |
Overcharge Protection Voltage | 54.7V |
Overcharge Recovery Voltage | 52.5V |
Equalization Turn-on Voltage | 51.75V |
Temperature Specification | |
Discharge Temperature | -20-60℃ |
Charge Temperature | 0-45℃ |
Storage Temperature | -5-45℃ |
BMS Over Temperature Protection | 65±5℃ |
BMS Over Temperature Protection Recovery | 55±5℃ |
Communication | |
Communication | / |
Compliance Specification | |
Certification | UN38.3 |
Diagram of maximum current discharge at different temperatures
Different constant power discharge curve
Plot of multiplier temperature rise
Cycle graphs of different DOD lifetime
2D Drawing
